Twin Cylinder Compressor

Technical Specifications
Repair Kits
Engine Application
Documents
Keywords

Technical Specifications

Brand YUMAK Orijinal

Cylinder Diameter Ø75 mm

Volume 442 cm³

Piston Operating Distance 50 mm

Port 0 M26x1.5

Port 2 M26x1.5

Port 4 M12x1.5

Port 8.1 M10x1

Port 9.1 M14x1.5

Port 9.2 M14x1.5

Crankshaft Thread M12x1.75 RH

Number of Cylinders 2

Cooling Water

ESS Feature Yes

Water Cooled Valve Plate Yes

Direct Working Yes

Maximum Operating Pressure 12.5 bar

Weight 17.5 kg

Repair Kits

Complete Cylinder Head

147 275 0710

RK.01.171

Daf

Repair Kit

147 275 0731

RK.01.161.05

Daf

Repair Kit

147 275 0735

RK.01.161.02

Repair Kit

147 275 0730

RK.01.161

Daf

Repair Kit

147 275 0732

RK.01.161.06

Daf

Repair Kit

147 275 0734

RK.01.161.04

Daf

Repair Kit

147 275 0736

RK.01.107

Daf

Repair Kit

147 275 0737

RK.01.220

Daf

Crankcase

301 275 0005

01.333

Daf , Solaris , Vdl Bus

Cylinder Head

303 275 0007

01.438

Renault , Daf , Solaris , Vdl Bus

Valf Pleyt

304 275 0107

01.439

Renault , Daf , Solaris , Vdl Bus

Crankshaft

302 250 0005

01.322

Daf , Solaris , Vdl Bus

Cooling Plate

305 275 0003

01.696

Renault , Daf , Solaris , Vdl Bus

Connecting Rod & Piston

315 075 0003

RK.01.811

Renault , Daf , Vdl Bus

Connecting Rod

308 032 0008

01.326

Renault , Iveco , Daf , Solaris , Vdl Bus

Piston & Ring

314 075 0004

RK.01.118

Mercedes-Benz , Man , Volvo , Renault , Iveco , Deutz , Daf , BMC , Cummins , Mack , John Deere , Paccar , Irisbus , Solaris , Vdl Bus , Kenworth , Peterbilt , Meritor , Freightliner , Case IH , Fendt , New Holland , Faun , Goldhofer

Piston & Ring

314 075 1004

RK.01.118.10

Mercedes-Benz , Man , Volvo , Renault , Iveco , Deutz , Daf , BMC , Cummins , Mack , John Deere , Paccar , Irisbus , Solaris , Vdl Bus , Kenworth , Peterbilt , Meritor , Freightliner , Case IH , Fendt , New Holland , Faun , Goldhofer

Piston & Ring

314 075 2004

RK.01.118.20

Mercedes-Benz , Man , Volvo , Renault , Iveco , Deutz , Daf , BMC , Cummins , Mack , John Deere , Paccar , Irisbus , Solaris , Vdl Bus , Kenworth , Peterbilt , Meritor , Freightliner , Case IH , Fendt , New Holland , Faun , Goldhofer

Piston & Ring

314 075 3004

RK.01.118.30

Mercedes-Benz , Man , Volvo , Renault , Iveco , Deutz , Daf , BMC , Cummins , Mack , John Deere , Paccar , Irisbus , Solaris , Vdl Bus , Kenworth , Peterbilt , Meritor , Freightliner , Case IH , Fendt , New Holland , Faun , Goldhofer

Piston & Ring

314 075 4004

RK.01.118.40

Mercedes-Benz , Man , Volvo , Renault , Iveco , Deutz , Daf , BMC , Cummins , Mack , John Deere , Paccar , Irisbus , Solaris , Vdl Bus , Kenworth , Peterbilt , Meritor , Freightliner , Case IH , Fendt , New Holland , Faun , Goldhofer

Piston

306 075 0005

01.911

Mercedes-Benz , Man , Volvo , Renault , Iveco , Deutz , Daf , BMC , Cummins , Mack , John Deere , Paccar , Irisbus , Solaris , Vdl Bus , Kenworth , Peterbilt , Meritor , Freightliner , Case IH , Fendt , New Holland , Faun , Goldhofer

Piston

306 075 1005

01.911.10

Mercedes-Benz , Man , Volvo , Renault , Iveco , Deutz , Daf , BMC , Cummins , Mack , John Deere , Paccar , Irisbus , Solaris , Vdl Bus , Kenworth , Peterbilt , Meritor , Freightliner , Case IH , Fendt , New Holland , Faun , Goldhofer

Piston

306 075 2005

01.911.20

Mercedes-Benz , Man , Volvo , Renault , Iveco , Deutz , Daf , BMC , Cummins , Mack , John Deere , Paccar , Irisbus , Solaris , Vdl Bus , Kenworth , Peterbilt , Meritor , Freightliner , Case IH , Fendt , New Holland , Faun , Goldhofer

Piston

306 075 3005

01.911.30

Mercedes-Benz , Man , Volvo , Renault , Iveco , Deutz , Daf , BMC , Cummins , Mack , John Deere , Paccar , Irisbus , Solaris , Vdl Bus , Kenworth , Peterbilt , Meritor , Freightliner , Case IH , Fendt , New Holland , Faun , Goldhofer

Piston

306 075 4005

01.911.40

Mercedes-Benz , Man , Volvo , Renault , Iveco , Deutz , Daf , BMC , Cummins , Mack , John Deere , Paccar , Irisbus , Solaris , Vdl Bus , Kenworth , Peterbilt , Meritor , Freightliner , Case IH , Fendt , New Holland , Faun , Goldhofer

Ring

307 075 0001

01.134

Mercedes-Benz , Man , Volvo , Scania , Renault , Iveco , Deutz , Daf , BMC , Magirus , Cummins , John Deere , Paccar , Irisbus , Solaris , Vdl Bus , Kenworth , Freightliner , Case IH , Fendt , New Holland , Faun , Goldhofer , Haldex

Ring

307 075 1001

01.134.10

Mercedes-Benz , Man , Volvo , Scania , Renault , Iveco , Deutz , Daf , BMC , Magirus , Cummins , John Deere , Paccar , Irisbus , Solaris , Vdl Bus , Kenworth , Freightliner , Case IH , Fendt , New Holland , Faun , Goldhofer , Haldex

Ring

307 075 2001

01.134.20

Mercedes-Benz , Man , Volvo , Scania , Renault , Iveco , Deutz , Daf , BMC , Magirus , Cummins , John Deere , Paccar , Irisbus , Solaris , Vdl Bus , Kenworth , Freightliner , Case IH , Fendt , New Holland , Faun , Goldhofer , Haldex

Ring

307 075 3001

01.134.30

Mercedes-Benz , Man , Volvo , Scania , Renault , Iveco , Deutz , Daf , BMC , Magirus , Cummins , John Deere , Paccar , Irisbus , Solaris , Vdl Bus , Kenworth , Freightliner , Case IH , Fendt , New Holland , Faun , Goldhofer , Haldex

Ring

307 075 4001

01.134.40

Mercedes-Benz , Man , Volvo , Scania , Renault , Iveco , Deutz , Daf , BMC , Magirus , Cummins , John Deere , Paccar , Irisbus , Solaris , Vdl Bus , Kenworth , Freightliner , Case IH , Fendt , New Holland , Faun , Goldhofer , Haldex

Roller Bearing

313 802 6307

00.441

Volvo , Iveco , Daf , Hino , Neoplan , Daf-Leyland , Alexander Dennis , Solaris , Vdl Bus , Seddon Atkinson

Bushing

312 035 0001

01.012

Mercedes-Benz , Man , Volvo , Scania , Renault , Iveco , Deutz , Daf , Ford , Mack , John Deere , Evobus , Neoplan , Paccar , Ikarbus , Solaris , Vdl Bus , Kenworth , Peterbilt , Meritor , Freightliner , Liebherr , Case IH , Fendt , New Holland , Faun , Goldhofer , Terex-Demag , Grove , Komatsu

Gear

309 027 0005

01.1587

Daf , Solaris , Vdl Bus

Show More

Engine Application

BrandModelEngine

DafKD

DafF75

DafF95

Daf75CF

Daf85CF

Daf95XF

DafXF95

DafCF85II

DafCF85C

Daf1260PP

Daf1260VS

DafTBR2175

Daf1160AVM

Documents

147 275 0701 request documents REQUEST

Keywords

147 275 0701 Twin Cylinder Compressor 01.05.069.10
