    Twin Cylinder Compressor

    YUMAK® No: 147 275 0200

    Old Code: 01.05.020
    CompareCompare

    GTIN

    OEM Numbers

    Wabco
    Daf

    Brands/Models

    Daf

    CKD ,

    F75 ,

    F95 ,

    CF75 ,

    CF85 ,

    95XF ,

    YTZ95 ,

    DESIGN
    TEST
    ORDER
    • WHATSAPP
    • SHARE
    • PRINT
    • E-Mail
    • Technical Specifications
    • Repair Kits
    • Engine Application
    • Documents
    • Keywords
    Technical Specifications

    Brand YUMAK Orijinal

    Cylinder Diameter Ø75 mm

    Volume 442 cm³

    Piston Operating Distance 50 mm

    Port 0 M26x1.5

    Port 2 M26x1.5

    Port 4 M12x1.5

    Port 8.1 M10x1

    Port 9.1 M14x1.5

    Port 9.2 M14x1.5

    Crankshaft Thread M12x1.75 RH

    Number of Cylinders 2

    Cooling Water

    Maximum Operating Pressure 12.5 bar

    Weight 18.2 kg

    Repair Kits
    147 275 0210

    Complete Cylinder Head

    147 275 0210

    RK.01.117

    Daf

    147 275 0231

    Repair Kit

    147 275 0231

    RK.01.123.01

    Daf

    147 275 0230

    Repair Kit

    147 275 0230

    RK.01.123

    Daf

    147 275 0234

    Repair Kit

    147 275 0234

    RK.01.123.04

    Daf

    147 275 0232

    Repair Kit

    147 275 0232

    RK.01.123.20

    Daf

    147 275 0236

    Repair Kit

    147 275 0236

    RK.01.107

    Daf

    147 275 0237

    Repair Kit

    147 275 0237

    RK.01.220

    Daf

    301 275 0005

    Crankcase

    301 275 0005

    01.333

    Daf , Solaris , Vdl Bus

    303 275 0005

    Cylinder Head

    303 275 0005

    01.323

    Daf

    304 275 0007

    Valf Pleyt

    304 275 0007

    01.325

    Daf

    302 250 0005

    Crankshaft

    302 250 0005

    01.322

    Daf , Solaris , Vdl Bus

    305 275 0001

    Cooling Plate

    305 275 0001

    01.324

    Daf

    315 075 0003

    Connecting Rod & Piston

    315 075 0003

    RK.01.811

    Renault , Daf , Vdl Bus

    308 032 0008

    Connecting Rod

    308 032 0008

    01.326

    Renault , Iveco , Daf , Solaris , Vdl Bus

    314 075 0004

    Piston & Ring

    314 075 0004

    RK.01.118

    Mercedes-Benz , Man , Volvo , Renault , Iveco , Deutz , Daf , BMC , Cummins , Mack , John Deere , Paccar , Irisbus , Solaris , Vdl Bus , Kenworth , Peterbilt , Meritor , Freightliner , Case IH , Fendt , New Holland , Faun , Goldhofer

    314 075 1004

    Piston & Ring

    314 075 1004

    RK.01.118.10

    Mercedes-Benz , Man , Volvo , Renault , Iveco , Deutz , Daf , BMC , Cummins , Mack , John Deere , Paccar , Irisbus , Solaris , Vdl Bus , Kenworth , Peterbilt , Meritor , Freightliner , Case IH , Fendt , New Holland , Faun , Goldhofer

    314 075 2004

    Piston & Ring

    314 075 2004

    RK.01.118.20

    Mercedes-Benz , Man , Volvo , Renault , Iveco , Deutz , Daf , BMC , Cummins , Mack , John Deere , Paccar , Irisbus , Solaris , Vdl Bus , Kenworth , Peterbilt , Meritor , Freightliner , Case IH , Fendt , New Holland , Faun , Goldhofer

    314 075 3004

    Piston & Ring

    314 075 3004

    RK.01.118.30

    Mercedes-Benz , Man , Volvo , Renault , Iveco , Deutz , Daf , BMC , Cummins , Mack , John Deere , Paccar , Irisbus , Solaris , Vdl Bus , Kenworth , Peterbilt , Meritor , Freightliner , Case IH , Fendt , New Holland , Faun , Goldhofer

    314 075 4004

    Piston & Ring

    314 075 4004

    RK.01.118.40

    Mercedes-Benz , Man , Volvo , Renault , Iveco , Deutz , Daf , BMC , Cummins , Mack , John Deere , Paccar , Irisbus , Solaris , Vdl Bus , Kenworth , Peterbilt , Meritor , Freightliner , Case IH , Fendt , New Holland , Faun , Goldhofer

    306 075 0005

    Piston

    306 075 0005

    01.911

    Mercedes-Benz , Man , Volvo , Renault , Iveco , Deutz , Daf , BMC , Cummins , Mack , John Deere , Paccar , Irisbus , Solaris , Vdl Bus , Kenworth , Peterbilt , Meritor , Freightliner , Case IH , Fendt , New Holland , Faun , Goldhofer

    306 075 1005

    Piston

    306 075 1005

    01.911.10

    Mercedes-Benz , Man , Volvo , Renault , Iveco , Deutz , Daf , BMC , Cummins , Mack , John Deere , Paccar , Irisbus , Solaris , Vdl Bus , Kenworth , Peterbilt , Meritor , Freightliner , Case IH , Fendt , New Holland , Faun , Goldhofer

    306 075 2005

    Piston

    306 075 2005

    01.911.20

    Mercedes-Benz , Man , Volvo , Renault , Iveco , Deutz , Daf , BMC , Cummins , Mack , John Deere , Paccar , Irisbus , Solaris , Vdl Bus , Kenworth , Peterbilt , Meritor , Freightliner , Case IH , Fendt , New Holland , Faun , Goldhofer

    306 075 3005

    Piston

    306 075 3005

    01.911.30

    Mercedes-Benz , Man , Volvo , Renault , Iveco , Deutz , Daf , BMC , Cummins , Mack , John Deere , Paccar , Irisbus , Solaris , Vdl Bus , Kenworth , Peterbilt , Meritor , Freightliner , Case IH , Fendt , New Holland , Faun , Goldhofer

    306 075 4005

    Piston

    306 075 4005

    01.911.40

    Mercedes-Benz , Man , Volvo , Renault , Iveco , Deutz , Daf , BMC , Cummins , Mack , John Deere , Paccar , Irisbus , Solaris , Vdl Bus , Kenworth , Peterbilt , Meritor , Freightliner , Case IH , Fendt , New Holland , Faun , Goldhofer

    307 075 0001

    Ring

    307 075 0001

    01.134

    Mercedes-Benz , Man , Volvo , Scania , Renault , Iveco , Deutz , Daf , BMC , Magirus , Cummins , John Deere , Paccar , Irisbus , Solaris , Vdl Bus , Kenworth , Freightliner , Case IH , Fendt , New Holland , Faun , Goldhofer , Haldex

    307 075 1001

    Ring

    307 075 1001

    01.134.10

    Mercedes-Benz , Man , Volvo , Scania , Renault , Iveco , Deutz , Daf , BMC , Magirus , Cummins , John Deere , Paccar , Irisbus , Solaris , Vdl Bus , Kenworth , Freightliner , Case IH , Fendt , New Holland , Faun , Goldhofer , Haldex

    307 075 2001

    Ring

    307 075 2001

    01.134.20

    Mercedes-Benz , Man , Volvo , Scania , Renault , Iveco , Deutz , Daf , BMC , Magirus , Cummins , John Deere , Paccar , Irisbus , Solaris , Vdl Bus , Kenworth , Freightliner , Case IH , Fendt , New Holland , Faun , Goldhofer , Haldex

    307 075 3001

    Ring

    307 075 3001

    01.134.30

    Mercedes-Benz , Man , Volvo , Scania , Renault , Iveco , Deutz , Daf , BMC , Magirus , Cummins , John Deere , Paccar , Irisbus , Solaris , Vdl Bus , Kenworth , Freightliner , Case IH , Fendt , New Holland , Faun , Goldhofer , Haldex

    307 075 4001

    Ring

    307 075 4001

    01.134.40

    Mercedes-Benz , Man , Volvo , Scania , Renault , Iveco , Deutz , Daf , BMC , Magirus , Cummins , John Deere , Paccar , Irisbus , Solaris , Vdl Bus , Kenworth , Freightliner , Case IH , Fendt , New Holland , Faun , Goldhofer , Haldex

    313 802 6307

    Roller Bearing

    313 802 6307

    00.441

    Volvo , Iveco , Daf , Hino , Neoplan , Daf-Leyland , Alexander Dennis , Solaris , Vdl Bus , Seddon Atkinson

    312 035 0001

    Bushing

    312 035 0001

    01.012

    Mercedes-Benz , Man , Volvo , Scania , Renault , Iveco , Deutz , Daf , Ford , Mack , John Deere , Evobus , Neoplan , Paccar , Ikarbus , Solaris , Vdl Bus , Kenworth , Peterbilt , Meritor , Freightliner , Liebherr , Case IH , Fendt , New Holland , Faun , Goldhofer , Terex-Demag , Grove , Komatsu

    309 027 0005

    Gear

    309 027 0005

    01.1587

    Daf , Solaris , Vdl Bus

    Show More
    Engine Application

    BrandModelEngine

    DafCKD

    DafF75

    DafF95

    DafCF75

    DafCF85

    Daf95XF

    DafYTZ95

    Documents

    147 275 0200 request documents REQUEST

    Keywords

    147 275 0200 Twin Cylinder Compressor 01.05.020 Wabco Daf 911 504 501 0 911 504 500 0 911 504 500 7 911 504 503 0 1310523 1310523R
